SN74HC595N
Description:
The SNx4HC595 devices contain an 8-bit, serial-in, parallel-out shift register that feeds an 8-bit D-type storage register. The storage register has parallel 3-state outputs. Separate clocks are provided for both the shift and storage register. The shift register has a direct overriding clear (SRCLR) input, serial (SER) input, and serial outputs for cascading. When the output-enable (OE) input is high, the outputs are in the high-impedance state.

Specification:
Number of Bits : 8
Pin Count : 16 dip
Logic Family : HC
Logical Function : Shift Register
High-Current 3-State Outputs Can Drive Up to 15 LSTTL Loads
Low Power Consumption
Output Type : 3-State
Propagation Delay Time : 285ns
Operating Supply Voltage (Typ) : 2.5/3.3/5V
Operating Temp Range : -55C to 125C
Operating Supply Voltage (Min) : 2V
Operating Supply Voltage (Max) : 6V
Operating Temperature Classification : Military
Mounting : Through Hole
Quantity: 25Pcs

Package Included:
25 x 74HC595N ICs
